Senal CSP-162 150W 6.5" Premium 2-Way Ceiling Speaker System (Pair)

Manufacturers Part #:

CSP-162

Quick Overview

  • Up to 150W Power Capacity For 70V, 100V, & Low-Ohm Systems Integrated Multi-Tap Transformer
  • Front-Baffle Located Tap Selector 6.5" Woofer 3/4" Titanium-Coated Tweeter
  • 7.5" Clearance Vented Port Enhances Low Frequencies Sealed Backcan Enhances Fidelity
  • Includes Drop-Ceiling Mounting Hardware

Free Expedited Shipping

Availability: Out of stock

More Views

Details

The CSP-162 150W 6.5" Premium 2-Way Ceiling Speaker System (Pair) from Senal is a pair of passive coaxial speakers that supports 70V, 100V, or low-ohm systems. It is designed to provide up to 150W of playback with low distortion for a variety of both commercial and residential applications.

It features a multi-tap transformer whose control is located directly on the front baffle of the speaker for easy access once installed, allowing you to adjust the wattage as well as bypass the transformer for use in a low impedance configuration. The CSP-162 has a 6.5" woofer and a 3/4" titanium-coated tweeter. The speaker has a sealed backcan, which enhances fidelity by preventing sound from being distributed into the ceiling. Additionally, a vented port helps improve low frequency response. The speaker has a clearance of 7.5" and the mounting bracket allows easy installation, even in a fixed ceiling. The included drop-ceiling mounting hardware allows you to install the CSP-162 in a drop ceiling configuration as well.

  • 110° coverage angle assures even distribution in both small and large areas
  • Removable locking connectors simplify wiring process
  • Attachment screw system streamlines installation while providing a secure mounting connection to most ceiling types
  • Secondary support tabs ensure additional security for building code compliance
  • Speaker grille can be painted to match decor

What's Included:

  • 2 x Cover Plate Door
  • Cutout Template
  • Drop-Ceiling Mounting Hardware
  • Grille Removal Key
  • Limited 3-Year Warranty
  • 2 x Removable Grille

Specifications
Input ConnectionsRemovable locking connector with screw-down terminals
Frequency Response75 Hz to 20 kHz
Power Capacity150 W
Maximum SPL90 dB SPL, 1 W @ 1 m
Transformer Tap70 V: 60, 30, 15, 7.5 W
100 V: 60, 30, 15 W
16 ohms transformer bypass
Coverage Angle110°
Low Frequency Driver6.5" (165 mm)
High Frequency Driver0.75" (19 mm)
Speaker Impedance16 ohms
Dimensions (H x W)7.5 x 8.7" (200 x 220 mm)
Width with Rim: 9.7" (246
mm)
Weight7.85 lb (3.56 kg)
